Welded Mesh Roll

Minimum Order Quantity: 100 Roll/Rolls
Supply Ability:1000 Roll/Rolls per Week
Payment Terms:L/C,T/T,Western Union

Categories : ,
Contact Now
  • Description
  • Place of Origin:Hebei China (Mainland)
  • Main Export Market:America, Europe, Australia, Mid-east, Africa, Asia
  • Price:US $5 – 42 / Square Meter
  • Price Valid Time:7 days
  • Company Certificate:ISO 9001：2008,CE,SGS
  • Quality Inspection:ISO 9001：2008,CE,SGS
  • HS Code:7314490000
  • Brand Name:DeChengli
  • Type:Welded Wire Mesh
  • Material:Low carbon steel wire, stainless steel wire, PVC wire.
  • Means of Transport:by sea
  • Delivery Date:within 20 days
  • Specification:Opening: 50*150mm,50*200mm
  • Applications:used in industry and agriculture building, transportation and mining for all such purposes
  • Packaging Detail:Wrapped with plastic film outside with high quality metal or wooden pallet. In bulk,nude packing or as customers’ requirements.
  • Delivery Detail:within 30 days after formal order

Specification:
1) Wire diameter: 8#-24#
2) Width: 0.5m-2.2m
3) Length: 12-45m
4) Mesh: 1/4″ 3/8″ 1/2″ 5/8″ 3/4″ 1″ 2″ 3″ 4″ 1″x1/2″ 2″x3″ 2″x4″
5) Type:in panel or in roll

Material:
High quality low carbon steel wire
Stainless steel wire

Classification:
1)Galvanized welded wire mesh:
* Electro galvanized welded wire mesh
* Hot-dipped galvanized welded wire mesh
2)PVC coated welded wire mesh
* PVC-dipped welded wire mesh
3)Special welded wire mesh

Surface treatment: elec-galvanized,hot-dip galvanized,pvc coated,powder coating etc.

Feature: The structure of this kind of wire mesh is strong, lasting and rust-resistant.Galvanized welded wire mesh is galvanized after welding.

Manufacture process: The galvanized electric wire mesh, welded after galvanized electric welded mesh and plastic coated mesh are made with high-quality iron wire by automatic equipment.

Weaving:Including galvanizing before or after welding.

Package:
The spare parts and control cabinet will be loaded in wooden box.
The main machine is nude packing.it need one 40′ GP container.

Hot Dipped Welded Wire Mesh

Specifications of?Welded Mesh Roll
Opening
Wire Diameter<BWG>
In inch
In metric unit(mm)
1/4″ x 1/4″
6.4mm x 6.4mm
22,23,24
3/8″ x 3/8″
10.6mm x 10.6mm
19,20,21,22
1/2″ x 1/2″
12.7mm x 12.7mm
16,17,18,19,20,21,22,23
5/8″ x 5/8″
16mm x 16mm
18,19,20,21,
3/4″ x 3/4″
19.1mm x 19.1mm
16,17,18,19,20,21
1″ x 1/2″
25.4mm x 12.7mm
16,17,18,19,20,21
1-1/2″ x 1-1/2″
38mm x 38mm
14,15,16,17,18,19
1″ x 2″
25.4mm x 50.8mm
14,15,16
2″ x 2″
50.8mm x 50.8mm
12,13,14,15,16
Technical Note:
1,Standard roll length: 30m;width: 0.5m to 2.4m
2,Special sizes available on request
3,Packing: in waterproof paper in rolls. Custom packing available at request.
Specifications of?Galvanized Welded Mesh Roll
Opening
Wire Diameter<BWG>
In inch
In metric unit(mm)
2″ x 3″
50mm x 75mm
2.0mm,2.5mm,1.65mm
3″ x 3″
75mm x 75mm
2.67mm,2.41mm,2.11mm,1.83mm,1.65mm
2″ x 4″
50mm x 100mm
2.11mm,2.5mm
4″ x 4″
100mm x 100mm
2.0mm,2.5mm
Technical Note:
1,Standard roll length:130m;width: 0.5m to 2.4m
2,Special sizes available on request
3,Packing: in waterproof paper in rolls. Custom packing available at request.
Specifications of PVC Coated Welded Mesh Roll
Opening
Wire Diameter<BWG>
In inch
In metric unit(mm)
1/2″ x 1/2″
12.7mm x 12.7mm
16,17,18,19,20,21
3/4″ x 3/4″
19mm x 19mm
16,17,18,19,20,21
1″ x 1″
25.4mm x 25.4mm
15,16,17,18,19,20
2″ x 2 “
50.8mm x 50.8mm
15,16,17,18,19,20
Technical Note:
1,Standard roll length: 30m;width: 0.5m to 2.4m
2,Special sizes available at request
3,Packing: in waterproof paper in rolls.special packing available on request.
